User manual - DATA RECORDER and cooperating software
10. USER'S SETTINGS LIST
Parameter Description Value
Description
page
Parameters in the "Measurements list options” menu
List type Type of measurement results list 45
Date, Time Position of time line on historical list 46
Parameters in the "Graph options” menu
Scale Setting time scale 46
Parameters in the "Channels list options” menu
Display Method of displaying results 46
Parameters in the “Device information ” menu
Version Device firmware version 48
Serial no Device serial number 48
Memory Available device's memory 48
Used Used memory 48
Time left Time until memory is full 48
Parameters in the “Display options ” menu
Backlight Method of display backlight operation 48
Brightness Brightness of display backlight 48
Contrast Display contrast 48
Parameters in the “Logging setup” menu
Write Recording mode 49
Triggering
Method of measurement recording, digital
input function
50
Rec. period Time interval for measurement recording 50
Channel 1 Type of recorded value 50
Channel 2 Type of recorded value 50
Channel 3 Type of recorded value 50
Channel 4 Type of recorded value 50
Channel 5 Type of recorded value 50
Channel 6 Type of recorded value 50
Channel 7 Type of recorded value 50
Channel 8 Type of recorded value 50
Settings for Channel 1 in “Inputs settings” menu
Name Measurement channel name 52
