User manual - DATA RECORDER and cooperating software
III. USER MANUAL FOR “ S-TOOLKIT ”
System requirements:
At least i486 computer,
Colour monitor with minimum resolution of 640 x 480,
1 MB of free hard drive space.
Designed for Windows
tested on Windows
®
XP, Windows
®
Vista, Windows
®
7, Windows
®
8
1. GENERAL CHARACTERISTICS
The
S-Toolkit
software enables configuration reading and writing operations, updating the
device firmware and obtaining basic information about devices through RS-485 serial interface.
This application enables to quickly and easily define device parameters in one of three possible
configuration models. The set of parameters can be transmitted directly to the device or stored
in a file for future use.
2. INSTALLATION AND STARTUP
The
S-Toolkit-install
file is designed to install the program.
The software can be downloaded
from our homepage www.kobold.com under product search "ZLS", selection of device type
(ZLS-1 / -2). In addition, the software is on the supplied CD. During installation follow the
directions provided
by
Installation wizard.
The wizard will create a folder called
S-Toolkit
on
the computer’s hard drive, program files will be placed in this folder. The shortcut to the
program will be placed in a location specified by the user.
Manual startup of the program is done using the
DLToolkit.exe
executable file. Directly after
startup the program will attempt to establish communication with the device in order to read the
current setup. The attempt to establish communications is executed using default (during initial
program startup) settings of RS-485 port options (baud rate 9600 b/s, address 0, port: COM2)
or setting defined by the user during previous launch of the program. If these settings are
different than the default, or those recently used, the program will signal the communications
error. After setting correct values in the
Interface options
tab, read the current configuration in
RS485 port settings
section using the
[Read from device]
button.
109
