3. TECHNICAL DATA
Power supply voltage
(depending on version)
External Fuse (required)
Power consumption
85...
230
...260 V AC/DC; 50 ÷ 60 Hz (separated)
or 19...
24
...50 V DC and 16 V...
24
...35 V AC
(separated)
T - type, max. 2 A
typically 7 VA; max. 12 VA
Measurement inputs
(depending on version)
U/I version:
mV/RTD/TC version:
up to 8 inputs 0÷5 V, 1÷5 V, 0÷10 V, 2÷10 V, 0÷20 mA
or 4÷20 mA, common ground
up to 8 inputs Pt100, Pt500, Pt1000 (with manual
connection switch 2 or 3-wire), K, S, J, T, N, R, B, E,
0÷60 mV, 0÷75 mV, 0÷100 mV or 0÷150 mV
Digital input 1 input 24 V DC, galvanic isolation
power consumption: 7,5 mA / 24 V,
isolation: 1 min @ 500 V DC.
Digital outputs 2 electronic relays, NO type, 24 V AC / 35 V DC /
max. 200 mA, overload protection
Recording cycle 1 sec./ 2 sec. / 5 sec. / 10 sec. / 15 sec. / 20 sec. /
30 sec. /1 min. / 2 min. / 5 min. / 10 min. / 15 min. /
20 min. / 30 min. / 60 min.
Communication interface RS-485, 8N1 / Modbus RTU, galvanic isolated
1 min @ 500 V DC,1200 bit/s ÷ 115200 bit/s,
USB PC,
USB Host (in front or in the back of the device) support
for standard USB FlashDrive devices
Display
Backlight color
LCD graphic display, 128 x 64 points, with backlight
white
Data memory 8 MB - version with USB Host interface
Protection level
version with USB interface IP 54 (front panel, after using waterproof cover)
IP 20 (housing and terminals)
Housing type
Housing material
Housing dimensions
Mounting hole
Assembly depth
Panel thickness
panel mounting
NORYL - GFN2S E1
96 x 96 x 100 mm
90,5 x 90,5 mm
102 mm
max. 5 mm
