User manual - DATA RECORDER and cooperating software
Parameter Description Value
Description
page
Unit Unit for measured value 53
Input type Type of input/sensor 53, 55
Hi value
Value displayed for maximum value of input
current
53, 56
Lo value
Value displayed for minimum value of input
current
53, 56
Dec. point Position of the decimal point 54
Filter Level of filtration of indications 52
Bias Shifting of measurement scale 57
Upper ext. Upper extension of measurement range 54
Lower ext. Lower extension of measurement range 54
AL1 mode Alarm 1 generation mode 52
Threshold 1 Threshold of alarm 1 52
Hysteresis 1 Hysteresis of alarm 1 52
AL2 mode Alarm 2 generation mode 52
Threshold 2 Threshold of alarm 2 52
Hysteresis 2 Hysteresis of alarm 2 52
Settings for Channel 2 in “Inputs settings” menu
Name Measurement channel name 52
Unit Unit for measured value 53
Input type Type of input/sensor 53, 55
Hi value
Value displayed for maximum value of input
current
53, 56
Lo value
Value displayed for minimum value of input
current
53, 56
Dec. point Position of the decimal point 54
Filter Level of filtration of indications 52
Bias Shifting of measurement scale 57
Upper ext. Upper extension of measurement range 54
Lower ext. Lower extension of measurement range 54
AL1 mode Alarm 1 generation mode 52
Threshold 1 Threshold of alarm 1 52
Hysteresis 1 Hysteresis of alarm 1 52
AL2 mode Alarm 2 generation mode 52
Threshold 2 Threshold of alarm 2 52
