1 — OVERVIEW
Curtis Model 3401T – August 2022 Return to TOC
pg. 4
CONVENTIONS
e following topics describe terms and notations used in this manual.
Numeral System Notation
e following table describes how this manual denotes decimal, binary, and hexadecimal numbers.
Note: e letter n in the format column represents a digit.
Numeral System Format Example
Decimal
Either of the following:
• nnn
• nnnd
• 127
• 127d
Hexadecimal
Either of the following:
• nnnh
• 0xnnn
• 62Ah
• 0x62A
Binary nnnb 1011b
In addition, some CANopen examples have hexadecimal values without notation. ose examples
are formatted with a monospace font and with the bytes delimited by spaces, as shown in the
following example:
21 FF 01 11 22 01 00 00
Miscellaneous Conventions
• All voltages listed in this manual are DC voltages.
• RO means read-only.
• RW means read-write.
• N/A means not applicable.

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
