5 — MONITOR PARAMETERS
pg. 45
Return to TOC Curtis Model 3401T – August 2022
OUTPUT MENU
e following table describes the parameters on the Output menu. ese parameters are used when
pin 8 is congured as a MOSFET driver.
OUTPUT MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE ACCESS LEVEL DESCRIPTION
PWM Duty
0x6700:00
0.0–100.0%
0–1000
16-bit Field
Intermediate
Indicates the PWM percentage when pin 8 is
congured as a driver.
Current
0x66E0:00
0–1000mA
0–1000
16-bit Field
Intermediate
Indicates the output current when the Output Mode
parameter species Current Mode.

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
