CAN MENU
e following table describes the parameters on the CAN menu.
Note: e CAN menu also contains the RPDO 1–4 Byte Map and TPDO 1–4 Byte Map menus, which
specify the objects for which the PDOs transmit and receive data.
CAN MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
CAN Node ID
0x2000:01
1–127
1–127
16-bit Field Intermediate
46
Species the device’s node ID.
CAN Baud Rate
0x2001:01
–1 to 4
–1 to 4
16-bit Field Intermediate
0
Species the 3401T’s baud rate:
–1 = 100 Kbps
0 = 125 Kbps
1 = 250 Kbps
2 = 500 Kbps
3 = 800 Kbps
4 = 1 Mbps
ECS CAN Node ID
0x3104:00
1–127
1–127
32-bit Field Intermediate
70
Species the node ID for the ECS.

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
