ODOMETERS MENU
e 3401T provides three odometers. e Odometers parameters reset the odometers.
Note: e parameters on the Odometers menu of the Monitor menu indicate the odometer data.
ODOMETERS MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
Reset Odometer 1
0x646E:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets odometer 1 to 0.
Reset Odometer 2
0x646F:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets odometer 2 to 0.
Reset Odometer 3
0x6470:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets odometer 3 to 0.
SENDERS MENU
e Senders parameters specify the types of data received by the switch 1–4 inputs.
SENDERS MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
Sender 1 Type
0x6300:00
Enumerated
0–3
32-bit Field Intermediate
0
Congures the switch 1 input:
0 = Switch Input
1 = Resistor Input
2 = Voltage Input
3 = Frequency Input (reserved)
Sender 2 Type
0x6301:00
Enumerated
0–3
32-bit Field Intermediate
0
Congures the switch 2 input:
0 = Switch Input
1 = Resistor Input
2 = Voltage Input
3 = Frequency Input (reserved)
Sender 3 Type
0x6302:00
Enumerated
0–3
32-bit Field Intermediate
3
Congures the switch 3 input:
0 = Switch Input
1 = Resistor Input
2 = Voltage Input
3 = HYD Fault Input (Curtis DC pump controller)
Sender 4 Type
0x6303:00
Enumerated
0–3
32-bit Field Intermediate
3
Congures the switch 4 input:
0 = Switch Input
1 = Resistor Input
2 = Voltage Input
3 = TRA Fault Input (Curtis DC traction controller)

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
