4 — PROGRAMMABLE PARAMETERS
pg. 29
Return to TOC Curtis Model 3401T – August 2022
4 — PROGRAMMABLE PARAMETERS
MAIN MENU....................................... p.31
— Model Number
— Serial Number
— CDEV
— OS Version
— LCD Backlight
— Speed Unit
— Language
— Battery Type
SET HOURMETERS MENU.................. p.32
— Input Hrm Password
— Conrm Input Password
— Status of Set Hourmeters
SET HOURMETERS SUBMENU..... p.32
— Reset KSI Hourmeter
— Reset TRA Hourmeter
— Reset HYD Hourmeter
— Set KSI Hourmeter
— Change Hrm Password
CAN MENU......................................... p.33
— CAN Node ID
— CAN Baud Rate
— ECS CAN Node ID
RPD O AND TPDO BYTE
MAP MENUS......................... p.34
— Length
— Map 1
— Map 2
— Map 3
— Map 4
— Map 5
— Map 6
— Map 7
— Map 8
BDI MENU......................................... p.37
— Nominal Voltage
— Charge Full
— Charge Empty
— Discharge Full
— Discharge Empty
— OCR Reset
— Integration Rate
— Lift Lockout
PASSWORD MENU............................ p.38
— OEM Menu Password
— USER Menu Password
— PIN Code
MAINTENANCE MENU....................... p.38
— Maintenance Interval 1
— Maintenance Interval 2
— Maintenance Interval 3
— Reset Maintenance Interval 1
— Reset Maintenance Interval 2
— Reset Maintenance Interval 3
ODOMETERS MENU........................... p.39
— Reset Odometer 1
— Reset Odometer 2
— Reset Odometer 3
SENDERS MENU................................ p.39
— Sender 1 Type
— Sender 2 Type
— Sender 3 Type
— Sender 4 Type
OUTPUT MENU................................... p.40
— Output Mode
— Driver Output Setting
RAMP MENU................................ p.40
— Ramp Up Time
— Ramp Down Time
INITIAL MENU.............................. p.41
— Initial PWM Duty
— Initial Time
CURRENT LIMIT MENU................ p.41
— Maximum Current
— Minimum Current
DITHER MENU............................. p.41
— Dither Period
— Dither Amount
PI MENU...................................... p.42
— Kp
— Ki
MISC MENU....................................... p.42
— Mode Saving
— PIN Code Source
— HYD Controller Enable
— Programmer Protocol
— Vehicle Cong

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
