4 — PROGRAMMABLE PARAMETERS
pg. 35
Return to TOC Curtis Model 3401T – August 2022
Table 4-1 PDO Byte Map Menus — CAN Indexes and Default Values
PARAMETER PDO CAN INDEX DEFAULT VALUE
Length RPDO1
0x1600:00
8
Map 1 RPDO1
0x1600:01
0x66010008
Map 2 RPDO1
0x1600:02
0x66030008
Map 3 RPDO1
0x1600:03
0x66040008
Map 4 RPDO1
0x1600:04
0x66000008
Map 5 RPDO1
0x1600:05
0x66020008
Map 6 RPDO1
0x1600:06
0x64170008
Map 7 RPDO1
0x1600:07
0x66060008
Map 8 RPDO1
0x1600:08
0x66050008
Length TPDO1
0x1A00:00
4
Map 1 TPDO1
0x1A00:01
0x66070008
Map 2 TPDO1
0x1A00:02
0x660C0008
Map 3 TPDO1
0x1A00:03
0x642C0020
Map 4 TPDO1
0x1A00:04
0x66110008
Map 5 TPDO1
0x1A00:05
0
Map 6 TPDO1
0x1A00:06
0
Map 7 TPDO1
0x1A00:07
0
Map 8 TPDO1
0x1A00:08
0
Length RPDO2
0x1601:00
7
Map 1 RPDO2
0x1601:01
0x66080008
Map 2 RPDO2
0x1601:02
0x66090008
Map 3 RPDO2
0x1601:03
0x660A0010
Map 4 RPDO2
0x1601:04
0x660D0008
Map 5 RPDO2
0x1601:05
0x660F0008
Map 6 RPDO2
0x1601:06
0x66100008
Map 7 RPDO2
0x1601:07
0x66140008
Map 8 RPDO2
0x1601:08
0
Length TPDO2
0x1A01:00
2
Map 1 TPDO2
0x1A01:01
0x660B0008
Map 2 TPDO2
0x1A01:02
0x690B0020
Map 3 TPDO2
0x1A01:03
0
Map 4 TPDO2
0x1A01:04
0
Map 5 TPDO2
0x1A01:05
0
Map 6 TPDO2
0x1A01:06
0
Map 7 TPDO2
0x1A01:07
0
Map 8 TPDO2
0x1A01:08
0
Length RPDO3
0x1602:00
4
Map 1 RPDO3
0x1602:01
0x660E0020
Map 2 RPDO3
0x1602:02
0x66150008
Map 3 RPDO3
0x1602:03
0x66160008
Map 4 RPDO3
0x1602:04
0x66170010
Map 5 RPDO3
0x1602:05
0
Map 6 RPDO3
0x1602:06
0
Map 7 RPDO3
0x1602:07
0
Map 8 RPDO3
0x1602:08
0

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
