4 — PROGRAMMABLE PARAMETERS
Curtis Model 3401T – August 2022 Return to TOC
pg. 36
PARAMETER PDO CAN INDEX DEFAULT VALUE
Length TPDO3
0x1A02:00
0
Map 1 TPDO3
0x1A02:01
0
Map 2 TPDO3
0x1A02:02
0
Map 3 TPDO3
0x1A02:03
0
Map 4 TPDO3
0x1A02:04
0
Map 5 TPDO3
0x1A02:05
0
Map 6 TPDO3
0x1A02:06
0
Map 7 TPDO3
0x1A02:07
0
Map 8 TPDO3
0x1A02:08
0
Length RPDO4
0x1603:00
2
Map 1 RPDO4
0x1603:01
0x66120020
Map 2 RPDO4
0x1603:02
0x66130020
Map 3 RPDO4
0x1603:03
0
Map 4 RPDO4
0x1603:04
0
Map 5 RPDO4
0x1603:05
0
Map 6 RPDO4
0x1603:06
0
Map 7 RPDO4
0x1603:07
0
Map 8 RPDO4
0x1603:08
0
Length TPDO4
0x1A03:00
0
Map 1 TPDO4
0x1A03:01
0
Map 2 TPDO4
0x1A03:02
0
Map 3 TPDO4
0x1A03:03
0
Map 4 TPDO4
0x1A03:04
0
Map 5 TPDO4
0x1A03:05
0
Map 6 TPDO4
0x1A03:06
0
Map 7 TPDO4
0x1A03:07
0
Map 8 TPDO4
0x1A03:08
0
Table 4-1 PDO Byte Map Menus — CAN Indexes and Default Values, cont’d

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
