Kohler CURTIS 3401T User Manual

4 — PROGRAMMABLE PARAMETERS
Curtis Model 3401T – August 2022 Return to TOC
pg. 38
PASSWORD MENU
e Password parameters specify the passwords for powering on the 3401T and for viewing and
editing parameters.
Note: e passwords’ ranges of values are 11111–55555. However, passwords can only consist of the
digits 1 through 5.
PASSWORD MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
OEM Menu Password
0x6011:00
11111–55555
11111–55555
32-bit OEM Dealer
22222
Species the password for accessing parameter
menus that have the OEM access level.
USER Menu Password
0x600F:00
11111–55555
11111–55555
32-bit Field Intermediate
11111
Species the password for accessing parameter
menus that have the User access level.
PIN Code
0x6010:00
11111–55555
11111–55555
32-bit Field Intermediate
12345
Species the password for powering on the 3401T.
Note: The PIN Code Source parameter indicates
whether a password is required.
MAINTENANCE MENU
e 3401T provides three countdown maintenance monitors. e Maintenance parameters specify
intervals for and reset the monitors.
Note: e parameters on the Maintenance menu of the Monitor menu indicate how much time
remains on the maintenance monitors.
MAINTENANCE MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
Maintenance Interval 1
0x643E:00
0.0–3276.7 hours
0–32767
32-bit Field Intermediate
999.9 hours
Species the countdown interval for maintenance
monitor 1.
Maintenance Interval 2
0x6444:00
0.0–3276.7 hours
0–32767
32-bit Field Intermediate
999.9 hours
Species the countdown interval for maintenance
monitor 2.
Maintenance Interval 3
0x644A:00
0.0–3276.7 hours
0–32767
32-bit Field Intermediate
999.9 hours
Species the countdown interval for maintenance
monitor 3.
Reset Maintenance
Interval 1
0x6471:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets maintenance monitor 1.
Reset Maintenance
Interval 2
0x6472:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets maintenance monitor 2.
Reset Maintenance
Interval 3
0x6473:00
Off/On
0–1
16-bit Field Intermediate
Off
Resets maintenance monitor 3.

Kohler CURTIS 3401T Specifications

Power

nominal voltage	12–96 VDC
minimum voltage	8 VDC
maximum voltage	120 VDC
keyswitch on current	33–207mA
keyswitch off current	25–112mA
LCD heater on current	566–801mA

Operating Environment

operating temperature with LCD heater	–40°C to +70°C
operating temperature without LCD heater	–20°C to +70°C
storage temperature	–40°C to +85°C

Weight and Dimensions

dimensions	160 x 102 x 49.7 mm
