5 — MONITOR PARAMETERS
Curtis Model 3401T – August 2022 Return to TOC
pg. 44
MAINTENANCE MENU
e following table describes the parameters on the Maintenance menu.
MAINTENANCE MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE ACCESS LEVEL DESCRIPTION
Maintenance 1
0x6803:00
0–3276.7 hours
0–32767
16-bit Field
Intermediate
Indicates the remaining time on maintenance
monitor 1.
Maintenance 2
0x6804:00
0–3276.7 hours
0–32767
16-bit Field
Intermediate
Indicates the remaining time on maintenance
monitor 2.
Maintenance 3
0x6805:00
0–3276.7 hours
0–32767
16-bit Field
Intermediate
Indicates the remaining time on maintenance
monitor 3.
SENDERS MENU
e parameters on the Senders menu indicate the raw AD data for switch inputs 1–4.
SENDERS MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE ACCESS LEVEL DESCRIPTION
Sender 1
0x6312:00
0–4095
0–4095
32-bit Field
Intermediate
Indicates the raw AD data for switch input 1.
Sender 2
0x6314:00
0–4095
0–4095
32-bit Field
Intermediate
Indicates the raw AD data for switch input 2.
Sender 3
0x6318:00
0–4095
0–4095
32-bit Field
Intermediate
Indicates the raw AD data for switch input 3.
Sender 4
0x631A:00
0–4095
0–4095
32-bit Field
Intermediate
Indicates the raw AD data for switch input 4.
ODOMETERS MENU
e following table describes the parameters on the Odometers menu.
ODOMETERS MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE ACCESS LEVEL DESCRIPTION
Odometer 1
0x6806:00
0–9999999
0–9999999
32-bit Field
Intermediate
Indicates the value of odometer 1.
Odometer 2
0x6807:00
0–9999999
0–9999999
32-bit Field
Intermediate
Indicates the value of odometer 2.
Odometer 3
0x6808:00
0–9999999
0–9999999
32-bit Field
Intermediate
Indicates the value of odometer 3.
