Kollmorgen AKM Series User Manual

35.2 Connector codes 1, 2, 7, B, C, G, H, T: AKM1 - AKM8
Examples: AKM52E-ANC2DB-00 or AKM11E-AN7NR-00
Model Connector code (PTC) Connector code (KTY 84-130)
AKM1 C 7
AKM2 B, C 1, 7
AKM3 - AKM7 C 1
AKM2 - AKM6 G -
AKM74Q, AKM82T H 1
AKM8 T 2
35.2.1 Power
Connector codes 1, 7, B, C, G for AKM1 - AKM7
Pin Function Pin Function
1U ABR+
W
PE
B
BR -
3 W C n.c
4
V
D
n.c.
Connector code 1, H for AKM74Q, AKM82T
Pin Function Pin Function
UU +BR+
VV - BR-
WW
W
PE
Connector code 2, T for AKM8
Terminal Function Terminal Function
U
Phase U
BR - Brake -
V
Phase V
BR + Brake +
W
Phase W
PE Protective Earth
General - 132 Servomotors AKM
Connector Pinout 04/2013 Kollmorgen
1
W
3
4
A
B
C
D
U
+-
W
V
W
U
V
W
PE
BR+
BR-
