2. Carry out electrostatic discharge on the top-hat rail or on the ground connection (not in the
Page - 62 -
6. Place the protruding end of the pull-out strip under the battery so that it does not come out of the
Battery compartment protrudes.
The data in RAM is buffered for up to 10 minutes due to gold capacitors. During this time, a
battery change is guaranteed without data loss.
Battery replacement
Note: It is recommended to replace the battery after 4 - 5 years of operation.
5. Insert new battery with correct polarity. To do this, the pull-out strip is lifted and the battery is inserted into the battery
compartment with the “+” side down. In order for the battery to be pulled out again, the pull-out strip must be
located above the battery.
Seal seam strength tester Labormaster HCT 3000
Operating instructions and technical description
6.3.2.
4. Remove the battery from the holder by pulling on the pull-out strip (do not touch the battery with pliers or non-insulated
tweezers ÿ risk of short circuit!). The battery may only be touched by hand on the front sides. Insulated tweezers
can also be used to remove it.
Grab the power supply!).
3. Remove the lithium battery cover using a screwdriver.
1. Open the control cabinet.
A notice:
Lithium batteries are hazardous waste! Used batteries must therefore be disposed of accordingly!
Inh. Ludwig P. Goals
Fax +49.7153.9510-100
Figure 32 / Battery handling
E-Mail: sales@kopp-online.de
Ulmer Straße 51 – 53
Willi Kopp e. K
http://www.kopp-online.de
D-73262 Reichenbach/Fils
Packaging systems
Phone +49.7153.9510-0
Subject to errors and technical changes!
Labormaster Version 2.6.3 SW 2.2 from 03/2016 Page 62 of 82, March 1, 2016
