3
Parts of the MR-2
Front and side panels
1. MICINexternalmicrophoneinputjack
(stereominijack;PlugInPowercompatible)
2. LINEINjack(stereominijack)
3. Headphonejack(stereominijack)
4. INPUTLEVELbutton
5. Builtinmicrophone(XYdirectionalstereomicrophone)
6. PEAKL/Rindicators
Theseindicatorslightupgreenatappropriatelevels,andlightupred
duringclipping.
HOLD switch
(to avoid accidental operation)
Battery
case cover
1
2
3
4
5
8
66
10
11
12
13
14
15
9
7
16
16
