Installation
9. For “Max. feed-in capacity” enter the value specified
to you by the energy supply company. Do this by
pressing “ENTER” and using the arrow keys to enter
the value. Confirm each digit with “ENTER”. At the
end, confirm the input with √.
10. Use the arrow keys to select the “Energy meter” field
and press “ENTER”. Select the energy meter fitted
from the list and confirm with “ENTER”.
11. Use the arrow keys to select the “Sensor position”
field and press “ENTER”. Select the position of the
energy meter fitted in the building services and
confirm with “ENTER”.
12. Press the right arrow key to go to the next installation
item.
P
The “Network IPv4” menu is displayed.
13. Press “ENTER” to activate the network protocol.
14. Enter the data relating to the network. This may be
a fixed IP address for the inverter or obtaining the IP
address automatically via DHCP. Confirm the entries
with “ENTER”.
15. Press the right arrow key to go to the next installation
item.
P
The “Modbus SunSpec (TCP)” menu is displayed.
16. If you need the Modbus SunSpec protocol via TCP,
e.g. for external connected monitoring of the inverter,
you can activate it here. To do this, press “ENTER” to
activate the Modbus SunSpec protocol.
17. Press the right arrow key to go to the next installation
item.
P
The "Solar portal" menu appears on the display.
INFO
You will find a list of approved energy
meters and their purpose in the
download area for the product on our
homepage at
www.kostal-solar-electric.com
INFO
Position 1 (home consumption) or 2
(grid connection) states the installa-
tion position for the energy meter in
the home network.
