© 2018 KOSTAL Solar Electric GmbH
Operation and operating the device
Extra options Release options Input of an activation code, e.g. to
connect a battery
Released options Shows the released options with the
possibility of deactivating them
Service menu
1
Service code input Input of service code
Reset settings Reset device to factory settings
Event list
2
Shows the last 10 events with
explanation
Energy management
3
Input of max. feed-in capacity
(default: max. inverter power)
Selection of energy meter and instal-
lation position, which was connected
on the inverter
Reset national
guideline
3
Reset the country setting
1
Following entry of the service code, additional menu items for configuring the inverter appear.
The code can be requested for installers from the Service team.
2
A maximum of 10 events are displayed. Information about events can be found in the "Event codes" chapter.
3
Only possible if the service code is entered.
