KROHNE OPTISONIC 6300 - Page 15

TECHNICAL DATA 2
15
OPTISONIC 6300
www.krohne.com09/2020 - 4006413102 - TD OPTISONIC 6300 V2 R02 en
Operating conditions
Temperature
TemperatureTemperature
Temperature
Process temperature Standard version: -40...+120°C / -40...+248°F
XT version: -40...+200°C / -40...+392°F
Ambient temperature Sensor: -40...+70°C / -40...+158°F
Standard (die-cast aluminium converter housing):
-40…+65°C / -40…+149°F
Standard (polyamide converter housing):
-40…+65°C / -40…+149°F
Option (die-cast stainless steel converter housing):
-40...+60°C / -40...+140°F
Ambient temperatures below -25°C / -13°F may affect the readability
of the display.
Protect the signal converter from external heat sources such as direct sunlight, as higher temperatures
reduce the life cycle of all electronic components.
Storage temperature -50…+70°C / -58…+158°F
Pipe specifications
Pipe specificationsPipe specifications
Pipe specifications
Material Metal, plastic, ceramic, asbestos cement, internal / external coated
pipes (coatings and liners fully bonded to pipe wall).
Pipe wall thickness < 200 mm / 7.87"
Liner thickness < 20 mm / 0.79"
Media properties
Media propertiesMedia properties
Media properties
Physical condition Liquid, single phase (well mixed, rather clean).
Viscosity < 200 cSt (general guideline)
Maximal measurable viscosity depends on density and pipe diameter
For higher viscosities please contact your local representative.
Permissible gas content (volume) d 2%
Permissible solid content
(volume)
d 5%
Flow range 0.1...20 m/s (turn down 200:1)
Installation conditions
Installation For detailed information refer to Installation and safety instructions
on page 29.
Measurement configuration Single path, single pipe or dual-path/dual-pipe
Inlet run t 10 DN straight length
Outlet run t 5 DN straight length
Dimensions and weights For detailed information refer to Dimensions and weight on page 25.
