2.2 Dimensions and weight
2.2.1 Housing
The weight of the F version in stainless steel is 13.5 kg / 29.8 lb.
Figure 2-1: Dimensions of housing
1 Field housing (F) - remote version
2 Wall-mounted housing (W) - remote version
Version Dimensions [mm] Weight [kg]
a b c g h
F 202 120 155 296 277 6.0
W 198 138 299 - - 2.4
Table 2-1: Dimensions and weight in mm and kg
Version Dimensions [inch] Weight [lb]
a b c g h
F 7.75 4.75 6.10 11.60 10.90 13.2
W 7.80 5.40 11.80 - - 5.3
Table 2-2: Dimensions and weight in inch and lb
