TECHNICAL DATA 2
17
OPTISONIC 6300
www.krohne.com09/2020 - 4006413102 - TD OPTISONIC 6300 V2 R02 en
Electrical connections
Description of used abbreviations; Q = flow rate; I
max
= maximum current; U
in
= input voltage; U
int
=
internal voltage; U
ext
= external voltage; U
int, max
= maximal internal voltage
General Electrical connection is carried out in conformity with the VDE 0100
directive "Regulations for electrical power installations with line
voltages up to 1000 V" or equivalent national specifications.
Power supply Standard: 100…230 VAC (15% / +10%); 50/60 Hz
Option: 24 VDC (tolerance range: -55% / +30%)
24 VAC/DC (AC: -15% / +10%; 50/60 Hz,DC; -25% / +30%)
Power consumption AC: 22 VA
DC: 12 W
Signal cable Use only the delivered, double shielded coax cables
Standard length: 6 m / 19 ft or 10 m / 32 ft
Optional: extension cable with cable (splitter) box: per 5 m / 16 ft up
to 30 m / 96 ft
To connect two sets of large rails a cable (splitter) box with an
extension cable is required.
Cable entries 1 or 2 cable entries for signal cables per flow converter
Standard: M20 x 1.5 (8...12 mm)
Option: ½" NPT; PF ½
