PRODUCT FEATURES 1
7
OPTISONIC 6300
www.krohne.com09/2020 - 4006413102 - TD OPTISONIC 6300 V2 R02 en
Single and dual path configuration
The OPTISONIC 6300 flowmeter uses the UFC 300 ultrasonic signal converter which is designed
to control one or two measuring paths continuously. The two paths can be used as a dual path
measurement on a single pipe for maximum reliability, or as two flowmeters on two separate
pipes for maximum flexibility.
Single path variants
Figure 1-2: Overview of single path variants
1 1 path installed on 1 pipe (small or medium sensor rail)
2 1 path installed on 1 pipe (2 large sensor rails in V-mode)
Dual-path variants
Figure 1-3: Overview of dual-path variants
1 2 path installed on 1 pipe (small, medium or large rails)
2 2 path installed on 2 pipes (small, medium or large rails)
3 2 path in X mode, installed on 1 pipe (medium rails)
