Technical Data of the Machine
93
Pos: 73.19 /BA/Ei nleitung/Technisc he Daten/Gros spackenpresse /BiG PACK 870_890_1270_ 1290 HS_1290 HD P HS/BiG PAC K 1290 HS/T echnisch e Daten: Mindest anforderung an d en Traktor Bi G PACK 1290 HS @ 190\ mod_138141234470 8_78.docx @ 1626898 @ @ 1
Minimum tractor requirements
Power requirement without cutting system
90 kW (122HP)
Power requirement with cutting system
105 kW (143 HP)
PTO speed
max. 1000 rpm
Max. operating pressure of hydraulic system
200 bar
Pos: 73.20 /BA/Ei nleitung/Technisc he Daten/Gros spackenpresse /BiG PACK 870_890_1270_ 1290 HS_1290 HD P HS/Technisc he Daten: El ektrische Ansc hlüsse All e HS Typen und HD P II @ 137\m od_13533286 70081_78.doc x @ 1216104 @ @ 1
Electrical connections
Lighting
12 V
7-pin socket
Power supply of the machine
12 V
3-pin socket
ISOBUS capable
yes
Pos: 73.21 /BA/Ei nleitung/Technisc he Daten/Gros spackenpresse /BiG PACK 870_890_1270_ 1290 HS_1290 HD P HS/Technisc he Daten: H ydraulikansc hlüsse Mediu m-Elektronik 87 0/ 890 HS/1270 H S/1290 HS @ 192\mod_1382342499 575_78.docx @ 1639613 @ @ 1
Hydraulic connections for medium version electronics
Control valve block
1x double-action control
unit
Pick-up lifting
1x single-action control
unit
With coaster/steering axle
1x single-action control
unit
Pos: 73.22 /BA/Ei nleitung/Technisc he Daten/Gros spackenpresse /BiG PACK 870_890_1270_ 1290 HS_1290 HD P HSTechnisc he Daten: Hydr aulikanschl üsse Komfort- Elektroni k alle HS Typen un d HDP II @ 303\ mod_1414130 233757_78.doc x @ 2356815 @ @ 1
Hydraulic connections for comfort version electronics
Control valve block
1x double-action control
unit
alternatively
1x single-action control
unit
1x depressurised return in
the tank
Pick-up lifting
1x single-action control
unit
Load Sensing connection on machine side
Standard
With hydraulic support jack design
1x double-action control
unit
