8 Terminal – machine functions [Medium Plus/Comfort Plus Electronics]
8.1 Status line
30
Supplement to Operating Instructions 150000773_00_en
BiG Pack 1270, BiG Pack 1270 XC, BiG Pack 1290, BiG Pack 1290 HDP, BiG Pack 1290 HDP XC, BiG Pack
1290 XC, BiG Pack 890, BiG Pack 890 XC
8 Terminal – machine functions [Medium Plus/Comfort Plus
Electronics]
WARNING
Personal injuries and/or machine damage caused by non-observance of alarm
messages
When alarm messages are ignored and the malfunction is not remedied, personal injuries
and/or serious damage to the machine could result.
 When alarm message is displayed, remedy the malfunction, refer to page84.
 If the malfunction cannot be remedied, contact KRONE customer service.
8.1 Status line
INFORMATION
Using a terminal with a resolution of less than 480x480 pixels.
On terminals with a resolution of less than 480x480 pixels, only 7 fields are displayed in the
status line. Thus, not all icons for the status line are shown.
On terminal with a resolution of more than/equal to 480x480 pixels, 8 fields are shown in the
status line.
EQ000-901
Icons displayed with shading (
) can be selected. If an icon with shading is selected:
• a window with further information opens or
• a function is activated or deactivated.
The status line shows the current states of the machine (depending on how it is equipped):
Icon Designation Explanation
Alarm message is pending refer to page84
Packer is conveying • The packer fills the bale channel with
crops.
• If the icon is displayed continuously, the
packer is being optimally utilised.
• If the depressed icon does not have a
black background, check the "Packer
feed" sensor.
