Machine Description 3
Intermediate universal shaft 3.3
Original Operating Instructions 150000802_00_en 31
KMG000-021
The machine data is on the type plate (1). The type plate is attached to the front of the chassis.
Information for enquiries and orders
When enquiring about the machine and ordering spare parts, state the year of manufacture, the
machine number as well as the type designation of the corresponding machine. To ensure that
these data is always available, we recommend to enter them in the fields on the front cover
page of these operating instructions.
3.3 Intermediate universal shaft
INFORMATION
Friction clutch
To ensure functionality and to increase the lifetime, vent the friction clutch once a year
before the harvest period. refer to page58.
KMG000-014
The intermediate universal shaft (1) for mower drive is connected with friction clutch (2) facing
the main gearbox. The friction clutch protects tractor and machine against damage.
