Start-up 7
Checking front end dimension 7.6
Original Operating Instructions 150000802_00_en 41
NOTICE
Changing the tractor
The machine could be damaged if the universal shaft length is not checked when changing
the tractor.
In order to avoid damage to the machine, check universal shaft length every time the
tractor is changed and correct it, if necessary, refer to page37.
KMG000-048
ü The machine is shut down and safeguarded, refer to page23.
Slide universal shaft (1) on PTO shaft end of tractor and secure it.
Secure universal shaft guard by means of supporting chain (2) against turning.
7.6 Checking front end dimension
KM000-265
INFORMATION
Depending on the country
If the front end dimension “A”3.5m is exceeded, the road safety must be ensured by means
of suitable aids (for example instructing accompanying person or mirror at the intersections),
refer to the leaflet for accessory equipment issued by Federal Minister of Transport.
