Information on This Document 1
How to use this document 1.5
Original Operating Instructions 150000802_00_en 9
Warnings of property damage/environmental damage
Warnings of property damage/environmental damage are separated from the remaining text
and marked with “Note”.
Example:
NOTICE
Gearbox damage due to low oil level
The gearboxes could be damaged when the oil level is too low.
Check gearbox oil level at regular intervals and top up oil, if necessary.
Check gearbox oil level approx. 3 to 4 hours after the machine has been switched off.
Check oil level only when machine is in horizontal position.
Notes with information and recommendations
Additional information and recommendations for trouble-free and productive operation of the
machine are separated from the remaining text and marked with “Information”.
Example:
INFORMATION
Each safety label is provided with an order number and can be ordered directly from the
manufacturer or from the authorized specialist dealer.
1.5.7 Conversion table
The following table is used to convert metric units to US units.
Size SI units (metric) Factor Inch-pound units
Unit name Abbreviatio
n
Unit name Abbreviatio
n
Area hectare ha 2.47105 acre ac.
Volumetric
flow
litres per minute L/min 0.2642 US gallons per
minute
gpm
cubic metres per
hour
m³/h 4.4029
Force newton N 0.2248 pound-force lbf
Length millimetre mm 0.03937 inch in.
metre m 3.2808 foot ft.
Power kilowatt kW 1.3410 horsepower hp
Pressure kilopascal kPa 0.1450 pound per
square inch
psi
megapascal MPa 145.0377
bar (non-SI) bar 14.5038
Torque newton metre Nm 0.7376 pound-foot or
foot-pound
ft∙lbf
8.8507 pound-inch or
inch-pound
in∙lbf
Temperature degree Celsius °C °Cx1.8+32 degree Fahren-
heit
°F
