Control and Display Elements 5
Hydraulic control units of the tractor 5.1
Original Operating Instructions 150000802_00_en 33
5 Control and Display Elements
5.1 Hydraulic control units of the tractor
Different functions of the machine are executed with the hydraulic control units of the tractor.
The following table explains the functions of the control units.
Designation Function
Single-acting control unit (1+) Float position
Lowers the mower from the transport position
into the working position.
(1+)
Lifts the mower from the working position into
the transport position.
