Maintenance - Lubrication 15
Lubrication chart - Machine 15.2
Original Operating Instructions 150000802_00_en 75
Lubricating intermediate universal shaft
KMG000-069
ü The machine is shut down and safeguarded, refer to page23.
Lubricate the universal shaft with multi-purpose grease at the intervals indicated in the
figure.
15.2 Lubrication chart - Machine
The information on maintenance intervals is based on average load of the machine. In case of
an increased load and under extreme working conditions, the time periods must be reduced.
The types of lubrication are marked by means of icons in the lubrication chart, refer to table.
Type of lubrication Lubricant Note
Grease Multi-purpose grease • Two strokes from the
grease gun per grease
nipple.
• Remove superfluous
grease at the lubrication
nipple.
KMG000-084
