Start-up 7
Checking/setting parallel lifting 7.3
Original Operating Instructions 150000802_00_en 39
WARNING! Increased risk of injury! Make sure when connecting (in particular during forward
travel of tractor) that there is no one between tractor and machine.
Lower the front lifting device hydraulically until the lower links (1) of the tractor are under the
lower link pins of the machine.
Drive the tractor forward up to the machine.
Raise the front lifting device hydraulically until the lower links (1) engage in the ball sleeves
and lock.
Secure tractor against rolling away.
Attach the top link (2) to the three-point hitch and secure it.
7.3 Checking/setting parallel lifting
NOTICE
If the machine does not lift in parallel with to the ground, the machine or the tractor
may be damaged.
If the machine does not lift in parallel with the ground, the universal shaft may bend
unfavourably. If the universal shaft is bent unfavourably, the machine will not run smoothly.
This may damage the machine or the tractor seriously.
To prevent damage, the machine must be aligned in parallel with the ground when it is
lifted.
Whenever mounting the machine again, check the parallelism of the machine to the
ground when it is lifted.
KM000-254
