Special equipment
79
Pos: 92.12 /Beipacks/ Mäher/EasyCut/ Hydraulische Federentla stung/mit CV/Entla stungsfedern abschr auben @ 60\mod_1297689010 746_78.docx @ 559987 @ @ 1
Unscrewing compensation springs
EC-375-0
b
a
b
a
d
b
d
c
Fig. 49
• Unscrew compensation springs (b) and place on machine
• Remove components (C) from the three-point block
• Remove adjusting lever (a) and put aside
• Remove safety chain with cotter pin from the three-point block and put aside
