III - 4
Before and After Use
Hydraulic brake (Export)
Certain export models are provided with a hydraulic brake.
These models require a brake valve on the tractor. The
corresponding hydraulic hose (1) is connected to the brake
valve on the tractor. The brake is activated by actuating
the brake pedal.
Hydraulic brake (auxiliary brake)
For certain operating conditions it is advisable to install a
hydraulic auxiliary brake to machines which normally do
not require a separate brake for the road journey. This
version requires an additional single acting control unit and
an additional free return line. The brake is activated by
actuating the control unit. Pressure is adjustable using the
pressure relief valve of the baler. The pressure relief valve
is adjusted to approx. 50 bar.
1
KR200032
CP103360
1
2
Net brake
When starting-up for the first time,
completely remove the protective tape from
the brake surface (1) of the net brake
disk (2).
