Krone Round Pack 1550 - Clogs in the Cutting System

V - 7
Basic Settings and Operation
Adjusting the Blade Safety Mechanism:
• Undo the lock nut (2).
• Turn the screw (1) until the desired measurement (a)
(see page V - 5) has been attained.
• Tighten lock nut (2).
If adjustment is not possible using the adjusting
screw:
• Unhook the spring (5) mounted on the slewing lever (9).
• Detach screw (8).
• Swivel the cylinder (3) to the side.
• Detach the slewing lever (9).
• Detach the selector disc (6) from the toothed blade
control shaft (7).
• Reattach the selector disc (6) by turning it one notch.
• Reassemble in reverse order.
5.3.7 Clogs in the Cutting System
If baling material or foreign objects clog the cutting
system:
• switch off the blades hydraulically
• start up the machine
• If it is not possible to clear the clog in this way, switch-
off the PTO shaft, attach the multi-purpose key (2) to
the intermediate drive shaft (1) and rotate clockwise
• The blade rotor, pick-up and tractor drive are reversed
• Detach the multi-purpose key (2) and store it correctly
in the transport mounting.
Risk of accidents!
Always detach the multi-purpose key from
the intermediate drive.
6
3
VP-1-063
2
1
5
7
8
9
RBV0423A
1
2
