III - 7
Before and After Use
3.4 Unhitching
• Always park the round baler on firm, level ground.
• If the baler must be parked on soft ground, increase the supporting surface of the jack
stand.
• Before unhitching, place wheel chocks under the wheels to prevent the round baler from
rolling.
• The tailgate must only be operated if the baler is attached correctly to the tractor. If this is
not respected there is a risk of tipping to the rear.
• Be careful when lowering the jack stand.
Risk of crushing!
• Depressurize the hydraulic system before disconnecting the hydraulic hoses.
• Remove the PTO shaft only if the motor is switched off.
Remove the ignition key.
Park the round baler on firm, level ground.
Place two wheel chocks (1) under the wheels to prevent
the baler from rolling.
The wheel chocks are located in front on both sides of the
machine.
KR-1-081
1
Set the jack stand in the support position
• Remove stake bolt (2), bring the support pipe out of the
jack stand (1) and then secure again with the stake bolt
(2).
• Crank the support plate (3) tightly onto the ground until
pressure on the the drawbar has been relieved.
CPB00090
1
3
2
CP400500
1
3.4.1 Parking Brake (optional)
The parking brake (1) is located on the front right of
the drawbar. Before hitching, the machine must be
secured by the parking brake to prevent it from
unintentional rolling away.
