V - 17
Basic Settings and Operation
Twine brake release setting
Move tensioning arm (2) from lower to central position.
In this position:
• tension spring (3) must not be under tension,
• wire rope (4) must be slightly released.
Adjusting lever (1) will release the brake at the start of the
binding cycle.
Adjustment depends on twine thickness.
Adjusting procedure:
• Turn screw (5) cw when using thick twine.
• Turn screw (5) ccw when using thin twine
CP400005
1
2
CP400006
2
4
3
