KTM 2013 1190 RC8 R EU/UK - Page 247

23 TECHNICAL DATA 245
Screw, gear sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, pulse generator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Camshaft drive sprocket bolt M6 14 Nm (10.3 lbf ft) –
Freewheel ring bolt M6 – 10.9 15 Nm (11.1 lbf ft)
Loctite
®
648™
Nut, cylinder head M6 9 Nm (6.6 lbf ft) –
Plug, vacuum connection M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Remaining engine screws M6 10 Nm (7.4 lbf ft) –
Screw, camshaft bearing support M6 – 10.9 10 Nm (7.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch spring M6 12 Nm (8.9 lbf ft) –
Screw, coolant connection on cylinder
head
M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6x60 10 Nm (7.4 lbf ft) –
Screw, engine case M6x80 10 Nm (7.4 lbf ft) –
Screw, engine case M6x90 10 Nm (7.4 lbf ft) –
Screw, freewheel holder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, locking lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) –
Screw, stator M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft) –
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
