23 TECHNICAL DATA 246
Screw, water pump wheel M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Stud, chain shaft M6 8 Nm (5.9 lbf ft) –
Vacuum connection M6 2.5 Nm (1.84 lbf ft)
Loctite
®
243™
Oil jet M6x0.75 4 Nm (3 lbf ft)
Loctite
®
243™
Plug, crankshaft retainer M8 15 Nm (11.1 lbf ft) –
Screw, camshaft bearing support M8 – 10.9 Step 1
10 Nm (7.4 lbf ft)
Step 2
18 Nm (13.3 lbf ft)
–
Screw, camshaft bearing support M8 – 10.9 Step 1
8.5 Nm (6.27 lbf ft)
Step 2
14.5 Nm (10.7 lbf ft)
Only applies when using:
Hex key bit (61229025000)
Screw, engine case M8 18 Nm (13.3 lbf ft) –
Screw, engine console M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, heat exchanger M8 15 Nm (11.1 lbf ft) –
Screw, timing chain guide rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Stud, exhaust flange M8 10 Nm (7.4 lbf ft) –
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –
Plug, cam lever axis M10x1 15 Nm (11.1 lbf ft) –
Plug, clutch lubrication M10x1 12 Nm (8.9 lbf ft) –
