23 TECHNICAL DATA 247
Screw, conrod bearing M10x1 Step 1
25 Nm (18.4 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
–
Screw, timing chain tensioner release M10x1 10 Nm (7.4 lbf ft) –
Spark plug M10x1 15 Nm (11.1 lbf ft) –
Cylinder head screw M11x1.5 Tightening sequence:
Using a crisscross pattern
Step 1
15 Nm (11.1 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
Step 4
90°
Lubricated with engine oil
Coolant temperature sensor M12x1.5 12 Nm (8.9 lbf ft) –
Rotor screw M12x1.5 90 Nm (66.4 lbf ft) –
Spark plug M12x1.5 15 Nm (11.1 lbf ft) –
Nut of engine sprocket M20x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Oil drain plug M20x1.5 20 Nm (14.8 lbf ft) –
Nut, inner clutch hub M22x1.5 130 Nm (95.9 lbf ft)
Loctite
®
243™
Plug, timing-chain tensioner M24x1.5 25 Nm (18.4 lbf ft) –
Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –
Nut, primary gear M33LHx1.5 130 Nm (95.9 lbf ft)
Loctite
®
243™
