Optional equipment
Precision Seed Drills
MAXIMA 2 M
101

Adjustments
Height adjustment
- Loosen screws (1).
- Set the required height:
• Clod clearer (2) must be set high enough to prevent
seeding unit from engaging in the soil.
• The independent knife coulter (3) enables preparing
the passage for the coulter and facilitates its
engagement in the soil.
- Tighten screws (1).
Lateral adjustment
- Unscrew the 4 bolts (1).
- Centre clod clearer (2) with regards to the seeding
line.
- Tighten the 4 bolts (1).
We recommend adjusting the clod clearer at
approximately 20 mm (0.78’’) from the ground.
Respect a distance L of 2 to 6 cm (0.78 - 2.36’’)
between the clod clearer (2) base and the
independent coulter (3) base.
Adjust the optional equipment height when
altering the sowing depth.
Adjust all seeding units to the same settings.
