Precision Seed Drills
102
MAXIMA 2 M
Optional equipment
Machine use
In very wet, sticky or stony conditions, the clod clearer
and coulter can be folded upwards or the equipment can
be removed from the seed drill.
3. Star shaped trash remover
Kit no. 1676783
The star-shaped trash remover is used to push aside
plant residues in order to prepare for the passage of the
seeding unit.
Adjustments
Height adjustment
- Remove lynch pin (1).
- Adjust working height using pin (2).
The working height can be adjusted to 10 different
positions.
- Insert and lock lynch pin (1).
The adjustment range is of 82.5 mm (3.25’’).
Adjust the optional equipment height when
altering the sowing depth.
