Precision Seed Drills
184
MAXIMA 2 M
Optional equipment
Working depth adjustment
- Loosen bolts (1).
- Position track eradicators in the required position.
- Tighten screws (1).
- Proceed the same way on the other side.
Share replacement
- Remove bolt (1) and nut (2).
- Remove and replace the worn coulter.
- Reinstall bolt (1) and nut (2).
• Torque: 8.1 daN m (59 lbf ft).
37. Offset of 160 mm (6’’)
Kit no. 1677247
Where trash removers are fitted to a circular knife
coulter, this equipment enables offsetting each disk
applicator of 160 mm (6’’) to the front of the beam.
Adjust track eradicator working depth in
order to eliminate the tracks made by the
tires on the ground.
Share Part no. B0000573
