Precision Seed Drills
44
MAXIMA 2 M
Putting into service
Adjustment of the side gauge wheels
The side gauge wheels must be positioned as close as
possible to the opener disks to allow their cleaning.
Adjustment:
- Raise machine using tractor lift.
- Stop the opener disks (1) from rotating manually.
- Using nut (2), adjust side gauge wheel (3) position.
The side gauge wheel (3) must be slightly in contact
with opener disk (1).
- Repeat procedure on the second side gauge wheel.
Proceed with this adjustment on each seeding unit.
Rotate gauge wheel at least by one turn to
check that it is free to rotate. Also check that
the opener disk is free to rotate.
