MAXIMA 2 M
Putting into service
 Positioning and parking
Fitting the control boxes
The control boxes must be easy to access from the
tractor cab.
Control boxes KMS412/KMS208 and KMD112:
- Drilling of 2 holes diameter 11 mm (1).
- 100 mm Hole to hole distance (2).
- Fit holder (3) using screws, washers and nuts (4).
- Position control box (5) using screws (6).
Control box HECTOR 3000:
The attachment is ensured by magnet (1).
Removing the control boxes
The control boxes must be stored in a dry place free of
dust.
