Precision Seed Drills
160
MAXIMA 2 M
Optional equipment
Adjusting the application depth
- Raise the machine.
- Remove lynch pin (1) and pin (2).
- Insert pin (2) in one of bracket (3) holes to set the
required working depth.
- Insert and lock lynch pin (1).
Adjust all applicators to the same setting.
In difficult working conditions, it is possible to lower the
applicator to improve the ground penetration:
- Remove nut and pin (1).
- Remove pin (2).
- Position the applicator pivot point in line with the lower
hole (3).
- Reinstall shaft (1).
- Reinstall nut.
- Position one of the control rod holes (4) in line with
hole (5) to adjust the working depth and lock with pin
(2).
- Insert and lock lynch pin.
The seeding unit setting must be adjusted
according to the sowing conditions (Soil
preparation and nature).
