Precision Seed Drills
90
MAXIMA 2 M
Instructions for work
Adjustment of the seeding unit lower stop
- Remove bolt (1) and nut (2).
- Position stop (3) according to the required setting:
• Position (a): Factory setting.
• Position (b): In this position, the seeding unit can
travel lower for improved ground contour following.
- Reinstall bolt (1) and nut (2).
The outer seeding unit stops can be adjusted in
this position for improved ground following when
sowing on field edges.
