Optional equipment
Precision Seed Drills
MAXIMA 2 M
145
Man. calibration
After having preset the microgranulator, it is necessary
to carry out a calibration test to know the real product
volume applied.
Preparing the machine:
- Divert a product transfer tube (1) towards a container.
- Position a container (2) underneath the metering unit.
Checking flow rate:
- Travel a distance of 100 m (328’1’’), or rotate the drive
shaft (1) through 64 revolutions to simulate the
100 m (328’1’’) distance.
The flow can vary according to the product,
the ambient temperature and the humidity
level.
Carry out a calibration test to check that the
microgranulator adjustment is correct.
