Precision Seed Drills
170
MAXIMA 2 M
Optional equipment
19. Filling auger
Kit no. 1677224
Loading screw for fertilizer fitted with 2 x 190 L
(2 x 50 US gal) or 2 x 260 L (2 x 67 US gal) hoppers.
Kit no. 1677226
Loading screw for fertilizer unit fitted with a
950 L (251 US gal) hopper.
The machine can be fitted with a loading screw for easier
hopper filling.
Hydraulic connections
Connect hydraulic hoses to the tractor double acting
spool valve.
Machine use
Lever (1) linked to the hatch enables altering the screw
flow.
