Precision Seed Drills
58
MAXIMA 2 M
Instructions for work
Adjusting the length (M)
- Loosen U-bolts (1).
- Move side marker extension (2) to obtain required
length M.
- Tighten U-bolts (1).
Repeat procedure for the second side marker.
Angle adjustment
- Loosen U-bolts (1).
- Pivot arm (2) to adjust the disc angle with regards to
the soil type.
- Tighten U-bolts (1).
Repeat procedure for the second side marker.
The spacer prevents deterioration of the
moving arm when tightening the screws.
You are recommended to check this setting in
the field, by inspecting several runs.
