Precision Seed Drills
86
MAXIMA 2 M
Instructions for work
Manual unit disengagement
To disengage a unit by hand, pull knob (1).
To engage a unit by hand, push and turn slightly knob (1)
to facilitate the unit engagement.
Seeding unit safety
When an incident occurs on one of the sowing units, the
safety bolt (2) shears causing the metering unit to stop.
- Disengage the unit.
- Use a punch to remove the remaining shear bolt part.
- Replace the components.
• Torque: 10 daN m (74 lbf ft).
Nuts (1) Part no. 80200640.
Safety bolt (2) Part no. N03273A0.
