Precision Seed Drills
50
MAXIMA 2 M
Instructions for transport
If the machine is fitted with a fertilizer with
2 x 190 L (2 x 50 US gal) hoppers or
2x260L(2x67US gal) hoppers:
- Activate cylinders to fold side markers.
- Lock side markers using valves (1) (1 on each
marker).
- Remove tube clip (1).
- Position side marker disk towards the machine inside.
- Insert and lock tube clip (1).
Repeat procedure for the other marker.
- Position pin (1) in upper hole (2).
The machine is in transport position.
Never engage the tractor PTO drive when the
machine is in transport position.
